Lead flashing in summer: why heat reveals failures that winter hid

Lead expands in heat and contracts in cold. Over a hot summer, it does both several times a day. That's when failures show up.

Lead flashing is the metal seal between your chimney and your roof. Without it, water finds a direct path into the gap where masonry meets tiles or slates, and from there into your ceiling.

It sits in several places around a chimney stack. The apron flashing covers the front face, where the chimney meets the slope below it. Step flashings run up each side, stepping with the tile courses. The back gutter sits behind the stack, collecting water that runs down from above and directing it away to either side.

On older properties, you'll also find lead soakers tucked under each individual slate or tile at the sides. These are thin pieces of lead, hidden from view, that work alongside the step flashings.

In the Henley conservation area, and across period houses throughout the Chilterns, lead is the standard material for all of this work. There's no substitute that performs as well over decades. It moulds to irregular shapes, it's durable, and when installed correctly it outlasts the building around it.

The problem is that "installed correctly" matters enormously. And a lot of lead on older roofs was not installed to modern standards, or has simply reached the end of its working life.

Lead is a soft metal. That's part of what makes it useful. It can be dressed to fit complex shapes and it doesn't corrode the way steel does. But that softness also means it moves.

In direct summer sun, a south-facing chimney apron can reach 80°C or higher. At night, the same piece of lead drops back toward ambient temperature. That's a swing of 50°C or more in a single day. Lead expands at roughly 29 millimetres per metre for every 10°C of temperature change. On a long run of flashing, that movement is significant.

Over years, this thermal cycling puts stress on any point where the lead is restrained. A mortar joint that was tight in February becomes a weak point in July. The lead wants to move; the mortar holds it in place. Something has to give. Usually it's the bond between lead and mortar, or the lead itself develops a crack at the point of stress.

Summer also softens the lead slightly, making it more vulnerable to physical stress. A heavy rainfall after a heatwave, with cold water hitting metal that's been baking all day, adds a thermal shock on top of the existing stress.

Oxidation plays a role too. Lead develops a patina of lead carbonate over time, which actually protects it. But where that patina is disrupted, by movement, by poorly applied coatings, or by abrasion, the underlying metal is more exposed. Long hot summers accelerate that process.

The result is that problems which were dormant through winter, perhaps sealed by debris or frost-swollen mortar, open up in summer and let water in. A damp patch that appears in June or July is often a lead failure that's been developing for years.

Splits at the chimney apron. The apron is the largest single piece of lead on most chimney stacks. It covers the full width of the front face and tucks under the tiles or slates below. Because it's a large piece, it moves more in total than smaller sections. Splits tend to develop across the width, often near the top where the lead is tucked into the mortar joint. Once a split opens, water tracks straight down the face of the chimney and into the roof space.

Separation from mortar bedding. Lead flashings are held at the top by being tucked into a raked mortar joint and then pointed over with fresh mortar. Over time, the mortar breaks down, the bond fails, and the top edge of the flashing lifts away from the masonry. You may be able to see this from ground level on some stacks, a visible gap or a section of lead that's pulling away from the brick. Water enters at the top and runs behind the flashing rather than over it.

Lifted step flashings. Step flashings on the sides of a chimney are particularly vulnerable to thermal movement because each piece is relatively short and is fixed at both ends. When the lead expands, it has nowhere to go. Over time, the fixings work loose or the mortar fails, and individual steps lift away from the chimney face. On 1900-1930s Reading semis, lifted step flashings are the most common chimney fault we see. The houses are the right age, the original lead is at or past its design life, and the chimneys often face south or west.

Fatigue cracks along the back gutter. The back gutter sits in a confined space between the rear of the chimney and the rising slope of the roof. It collects a large volume of water and it's subject to constant thermal movement. Fatigue cracks, fine hairline splits caused by repeated expansion and contraction over many years, develop along the length of the gutter. These are difficult to spot without getting close to the stack, but they allow steady water ingress even in moderate rainfall.

When a homeowner spots a gap or a crack in lead flashing, the instinct is often to reach for a tube of silicone sealant. It's quick, it's cheap, and it looks like it fills the gap. It doesn't work.

Silicone doesn't bond reliably to oxidised lead. It can hold for a few weeks, sometimes a few months, but it has no flexibility to match the thermal movement of the lead beneath it. When the lead expands in the next heatwave, the silicone breaks away. Often it peels back and creates a channel that directs water into the joint rather than away from it.

More importantly, silicone hides the underlying problem. A split in an apron or a failed mortar joint needs proper repair. Covering it with sealant delays that repair and usually makes it worse by the time a roofer eventually opens it up.

There is no sealant-based fix for lead flashing that holds long-term. The lead needs to be repaired or replaced.

Correct lead flashing work starts with the right material. For chimney flashings, the minimum is code 5 lead, which is 1.8 millimetres thick. Code 4, at 1.25 millimetres, is sometimes used for soakers, but code 5 is the standard for any exposed flashing. Thinner material is more vulnerable to fatigue and thermal damage.

Laps between sections need to be correct. A minimum 100mm lap prevents water from tracking back through the joint by capillary action. The lead is dressed into a raked mortar joint, fixed with lead wedges, and pointed with a mortar mix that allows slight movement rather than locking the lead rigid.

On any run longer than 1.5 metres, expansion joints are formed by overlapping sections rather than running a single piece. This gives the lead room to move without building up stress at a fixed point.

All of our lead work follows Lead Sheet Training Academy standards and complies with British Standard 5534. We've been doing this work for 40 years, across everything from Victorian terraces in Reading to listed properties in the Henley conservation area. Our heritage roofing experience covers churches, listed buildings, and complex chimney stacks where the lead work is as much about preservation as waterproofing.

The difference between a repair that lasts 20 years and one that fails in two comes down to the standard of the original installation.

If you've noticed a damp patch, a stain on a chimney breast, or water appearing after rain, don't leave it. Summer is the right time to get eyes on the lead while failures are visible. Book a free chimney inspection and we'll provide a full photographic report of the chimney and lead work, so you know exactly what you're dealing with before any work starts. If you have an active chimney leak repair that needs urgent attention, get in touch and we'll prioritise it.
